Which One Is More Expensive? Butterfly Valves or Ball Valves?
The butterfly valve and ball valve can be used in the pipeline to control the flow. Then, how to choose them? Which one is more expensive? The butterfly valve or the ball valve?
The butterfly valve and ball valve are two very simple structures of the valve, but the ball valve is more used in small diameter. The butterfly valve is more used in large diameter pipes. If it is the same specification parameters, the price of the ball valve is more expensive than that of the butterfly valve. What’s more, the volume and the weight of the ball valve will be much larger. However, because the butterfly valve and ball valve are two completely different valves, a variety of uses are also different. The simple comparison of the butterfly valve and the ball valve is meaningless. Use the right valve in the right working environment. Then, it can play its function and has better service for us.
Since you do not care about the price of the butterfly valve and ball valve, then when can we use the butterfly valve? When can we use the ball valve?
The selection principle of the butterfly valve:
1. Because the pressure loss of butterfly valves is larger than that of gate valves and ball valves, it is suitable for the pipeline system with less strict pressure loss requirements.
2. Because the butterfly valve can be used for flow regulation, it is suitable for selection in the pipeline that needs flow regulation.
3. Due to the structure and sealing material of the butterfly valve, it is not suitable for a high temperature and high pressure pipeline system. The general operating temperature is below 300 ℃, and the nominal pressure is below PN40.
4. Because the structure length of the butterfly valve is short. It can be made into a large mouth. We should choose butterfly valves if the structure length is short and the diameter of the valves needs large (such as DN1000 above).
5. Because the butterfly valve can be opened or closed only by rotating 90 degrees, it is appropriate to choose the butterfly valve in the case of fast opening and closing.
The selection principle of ball valves:
1. If the pipeline should be cleaned, and the valve needs to be buried in the ground on the oil, natural gas transmission main line, all-pass and all-welded structure of ball valves are selected. If the valves need to be buried on the ground, we can choose a flanged ball valve or a full bore welded one. The flanges, welding, full bore or reduced bore ball valve can be chosen for the branch pipe.
2. Use a flanged ball valve on the product oil pipeline and storage equipment.
3. The flanged and internal threaded floating ball valve can be used on the city gas and natural gas pipeline.
Which one is more expensive? The butterfly valve or the ball valve? We can't just choose the expensive ones, and we have to choose the right ones. It is most important to choose the valve suitable for our working conditions and pipeline requirements. If you are still confused about the selection of butterfly valve and ball valve products, you can call us-Landee Valve. We, Landee Valve will provide you with professional product selection guidance.
