Cast Steel Ball Valve
Cast steel ball valves are a series of ball valve products with many types, having a very wide range of applications in petroleum, long-distance pipeline, chemical, electric power and other industries. They are mainly used in pipelines to cut off, distribute and change the flow directions of media. With a cast steel body, this type of ball valve can be quickly opened and closed by manually rotating the handle 90 degrees. Simple structure, good sealing, relatively small volume and driving torque, and being easy to make open-close operation are all the characteristic features of them. What's more, cast steel ball valves are not only suitable for water, solvent, acid, natural gas and other general media, but also proper for poor conditions, like hydrogen peroxide, methane and ethylene.
Product Feature: Cast Steel.
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2 - 60 Inch (DN50 - DN1500).
End Connection: BW, RF Flanged.
Pressure Range: 150 - 2500 LB (PN16 - PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro-Hydraulic Actuator, Gas-Over-Oil Actuator.
Working Temperature: -46℃ - +200℃.
Product Feature: Cast Steel.
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2 - 60 Inch (DN50 - DN1500).
End Connection: BW, RF Flanged.
Pressure Range: 150 - 2500 LB (PN16 - PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro-Hydraulic Actuator, Gas-Over-Oil Actuator.
Working Temperature: -46℃ - +200℃.
