Trunnion Ball Valve, 12 Inch, 600 LB, PN100, WCB, API 6D, RF
Key Specifications / Features
Hits: 27
Trunnion Ball Valve Fabricator: Trunnion Mounted Ball Valves, 12 Inch, Class 600 LB, PN100, ASTM A216 WCB, API 6D, RF, Flanged RF Ends, ASME B16.10.
Tags
Detail Information
Name: Trunnion Ball Valve, ASTM A216 WCB, 12 Inch, 600 LB (PN100), Flanged RF Ends, API 6D
Design standard: API 6D.
Body material: ASTM A216 WCB.
Nominal diameter: 12 Inch.
Pressure: Class 600 LB (PN100).
End connection: RF.
Face to face: ASME B16.10.
Working temperature: -29℃ - +427℃.
Test and inspection: API 598.
Product Range
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 2-60 Inch (DN50-DN1500).
End connection: BW, Flanged.
Pressure range: Class 150-2500 LB (PN16-PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro-hydraulic actuator, Gas over oil actuator.
Working temperature: -46℃ - +200℃.
Design standard: API 6D.
Body material: ASTM A216 WCB.
Nominal diameter: 12 Inch.
Pressure: Class 600 LB (PN100).
End connection: RF.
Face to face: ASME B16.10.
Working temperature: -29℃ - +427℃.
Test and inspection: API 598.
Product Range
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 2-60 Inch (DN50-DN1500).
End connection: BW, Flanged.
Pressure range: Class 150-2500 LB (PN16-PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro-hydraulic actuator, Gas over oil actuator.
Working temperature: -46℃ - +200℃.
